CR Sheet

Catalog

CR or Chloroprene rubber, Also known as Neoprene, is a synthetic rubber. It has an excellent mechanical and good abrasion properties even without reinforcing filters and has a reasonable resilience in grades over 60° shore A. It displays good resistance to heat, ozone, oil and weathering and also gives good adhesion to metal. The recommended operating temperature range is between -40°C to +125°C. It has good resistance to inorganic hydrocarbons.

Inquiry now Contact us

Introduction

Application

Chloroprene rubber sheet is widely used in automotive applications such as gaskets, seals, Industrial Hoses & Belts, marine application, Fire retardant application, Electrical panel lining, Chemicals and oil resistance etc.

Parameter

CR RUBBER SHEET
Code	Colour	Specific Gravity	Hardness (±5)	Tensile Strength	Elongation	Polymer content	Finish Type
Code	Colour	Gm/cm³	SHORE A	Kg/cm²(min)	% (min)	Polymer content	Finish Type
ECONOMIC RANGE
NE70145	Black	1.45	70	40	200	10%	Smooth/Fabric
NE50145	Black	1.45	50	40	200	10%	Smooth/Fabric
NE80145	Black	1.45	80	40	200	10%	Smooth/Fabric
NE70140	Black	1.45	70	50	250	30%	Smooth/Fabric
ECONOMIC RANGE
NE65140	Black	1.4	65	50	250	50%	Smooth/Fabric
NE50140	Black	1.4	50	50	250	50%	Smooth/Fabric
PREMIUM RANGE
NE65140	Black	1.4	65	100	500	100%	Smooth/Fabric
NE60145	Black	1.45	60	150	250	100%	Smooth/Fabric
ZENA-PRENE AS PER BS2752
C40	Black	1.35	40	90	450	100%	Smooth/Fabric
C50	Black	1.35	50	120	400	100%	Smooth/Fabric
C60	Black	1.35	60	130	250	100%	Smooth/Fabric
C70	Black	1.35	70	130	200	100%	Smooth/Fabric
C80	Black	1.35	80	130	200	100%	Smooth/Fabric
CHLOROPRENE RUBBER SHEETS - FOOD GRADE
Code	Colour	Specific Gravity	Hardness (±5)	Tensile Strength	Elongation	Polymer content	Finish Type
Code	Colour	Gm/cm³	SHORE A	Kg/cm²(min)	% (min)	Polymer content	Finish Type
NE65145 FG	offwhite	1.45	65	50	250	100%	Smooth/Fabric
Standard Length	10 Mtr	33 Ft	11 Yard
Standard Width	1.2/1.4/1.5/2 Mtr	4/4.6/4.92/6.56 Ft	1.33/1.53/1.64/2.18 Yard
